Our high-quality pneumatic actuators provide efficient control for your valve operations. We understand that efficient control can directly impact your business operations, that's why our products are designed to deliver optimum performance, ensuring minimal downtime and a high degree of reliability.
ISO is the global standard used worldwide (Europe, America, and Asia). Its goal is to make sure cylinders from different brands have the same size and mounting dimensions.
Benefit:If you buy an ISO cylinder, it is easy to replace your old one, no matter the brand.
VDMA is the German industrial standard. It was very popular in the early European market. Today, most VDMA standards have been upgraded to ISO standards.
VDMA 24562 = ISO 15552 (They are the same).
VDMA 24563 = ISO 6432 (They are the same).
VDMA 24561 (Compact Cylinder): This does not have an exact ISO equivalent yet.
JIS is the Japanese Industrial Standard. It is mainly used for the Japanese market and Japanese machinery (like SMC style). Its dimensions are different from European standards.
VDMA & ISO: They are usually interchangeable. You can replace VDMA with ISO.
JIS: It is different. Do not mix JIS with ISO/VDMA!
| ISO 15552 – Standard Profile Cylinders | ||||
| Cylinder Standard | Cylinder Type | Brand | Series / Model |
|
| ISO 15552 | Standard Cylinder | FESTO | DNC |
 |
| ISO 15552 | Standard Cylinder | SMC | CP96 |
 |
| ISO 15552 | Standard Cylinder | AIRTAC | SI(SAI) / SE |
  |
| Manufacturer-Specific Standard | Standard Cylinder | AIRTAC | SC / SU(SAU) / SCT |
   |
| ISO 6432 – Mini / Round Cylinders | ||||
| Cylinder Standard | Cylinder Type | Brand | Series / Model | |
| ISO 6432 | Mini Cylinder | FESTO | DSNU-S |
 |
| ISO 6432 | Mini Cylinder | SMC | C85/C75 |
 |
| ISO 6432 | Mini Cylinder | AIRTAC | MI |
 |
| Manufacturer-Specific Standard | Mini Cylinder | AIRTAC | MAL(MBL) / MA |
  |
| ISO 21287 – Compact Cylinders | ||||
| Cylinder Standard | Cylinder Type | Brand | Series / Model | |
| ISO 21287 | Compact Cylinder | FESTO | ADN |
 |
|
Manufacturer-Specific Standard |
Compact Cylinder | SMC | CDQ2 |
 |
| Manufacturer-Specific Standard | Compact Cylinder | AIRTAC | SDA |
 |
| Manufacturer-Specific Standard | Compact Cylinder | FESTO | ADVU | |
| JIS | Compact Cylinder | AIRTAC | ACQ | |
The difference between standard pneumatic cylinders and thin pneumatic cylinders?
The main differences between standard pneumatic cylinders and thin pneumatic cylinders are installation space, cylinder diameter, stroke, and applicable.
What is the general pressure of a standard cylinder?
The general pressure of a standard pneumatic cylinder is 0.6 mpa, which is applicable to the working pressure of the cylinder and is a basic requirement for the normal operation of the cylinder.
How standard cylinders work in packaging machinery, filling machines?
During the product packaging process, the opening and closing movement of the pneumatic actuator SC standard pneumatic cylinder is required to seal the plastic bag.
During the liquid filling process, the stroke movement of the pneumatic actuator SC standard pneumatic cylinder is required to ensure that the bottle reaches the designated position or to execute the instruction to open the liquid.
What are the applications of mini pneumatic cylinders in the textile industry?
Mini pneumatic cylinders like MA, MAL, and MI are widely used in the textile industry for embroidery machines, sock knitting machines, hat machines, pocket machines, and zipper machines.
